排渣分离机reject separator
用途/特点
该机主要用于occ处理系统中的尾渣筛选。螺旋排列的转子刀片高速旋转时,在喷水装置和挡板作用下,淘洗作用强,处理后的杂质不含纤维,水分含量低。封闭筛选,操作环境好。
application/ features
used for tailing screen in occ system.
when rotating at high speed, rotor blades in spiral arrangement have strong washing function under the action of shower and baffle plate. so. the impurities after being treated by this equipment will not comprise fiber with low moisture content.
screening is closed and operation environment is good.
主要技术参数main technical parameters
型号 |
zsz1 |
zsz2 |
规格standard(mm) |
φ280 |
φ380 |
入口浓度inlet consistency(%) |
1~3.5 |
1~3.5 |
排渣浓度reject consistency(%) |
15~20 |
15~20 |
生产能力capacity(t/d) |
10~20 |
20~35 |
配用功率power of motor(kw) |
37kw |
55kw |
外形尺寸(长l×宽w×高h):mm |
2610×1925×1010 |
3200×2020×1195 |
|
